Selecting a crane of the EOT type is one of the most crucial tasks for industries where moving materials, machines, and equipment is a regular process. The choice of either single-girder or double-girder cranes can have an impact on the initial cost, lifting capacity, headroom, maintenance and further costs of operation. Both types of cranes are suitable for various material handling needs, but the structural design of each type is different. When comparing single girder vs double girder EOT crane, these factors should be considered carefully.

What Is the Difference Between Single Girder and Double Girder EOT Cranes?

The fundamental difference between the two types is related to the number of main girders used for the construction of the bridge of the crane. For a single girder crane, there is only one main girder; the hoist is mounted on this girder, under or on the side of it. For a double-girder crane, there are two main girders located parallel to each other.

This difference is going to have an impact on the total weight of the crane, its lifting capacity, headroom, span and performance. A single-girder crane may be used for general purposes, while a double-girder crane is worth considering in case of some specific needs. This is an important aspect when evaluating single girder vs double girder EOT crane options.

1. Initial Cost and Investment

Initial cost is one of the early criteria that companies evaluate while buying EOT cranes. Single-girder cranes usually have relatively simple bridge structures and require fewer structural elements. It may become a viable solution if the material handling does not need considerable lifting ability and a large crane structure.

The construction of double girder cranes includes two girders and a larger bridge design. Therefore, its initial cost may turn out to be higher, depending on the needed lifting ability, span, hoisting machinery and structure.

2. Lifting Capacity

Lifting Capacity is one of the most important differences between the two types of cranes that need to be evaluated while making your choice. Single girder cranes are usually chosen for light and medium duty applications where the material weight is within crane capabilities.

Double girder cranes might be appropriate for heavy-duty use. The double girder system results in a stronger structure and allows lifting applications to be done under proper design conditions.

Prior to choosing a crane, the business needs to know the maximum load that will be picked up, not the average load. The lifting requirement is therefore an important part of a single girder vs double girder EOT crane comparison.

3. Span and Structural Requirements

Span is the distance that is traversed by the crane from one end of the runway track. The span required is dependent on the dimensions of the building and the area over which the materials have to be handled.

A single girder crane can be used for most moderate span applications provided the structure is adequately designed for the load that is to be picked up. Double girder structures could be considered where the requirements of the structure are higher because of the load and span considerations.

The crane runway, the columns and other structural elements should be able to withstand the loading that occurs.

4. Hoist Height and Headroom Availability

Headroom availability may become a crucial factor in case there is a scarcity of vertical space inside the building. The location of hoist machinery with regard to main girders impacts the headroom availability. In the case of a single girder setup, the hoist normally operates beneath the main girder.

A double girder setup may offer additional options in terms of the placement of hoist machinery. It may be useful in case more hook height is required. Prior to purchasing the crane, business organizations need to assess building height, roof configuration, runway location, and hoist height.

5. Duty Cycle and Operation Conditions

Another factor that may impact the choice of crane is the frequency of its operation. A crane used rarely for loading machines differs from a crane used continuously during the production cycle.

Single girder cranes can be used for applications where the number of lifts per hour and load conditions fall within their designed Capacity. Double girder cranes can be considered for applications where there is a heavy load to be lifted.

Factors like the number of lifts per hour, number of operating hours, load distribution, and the operating environment need to be considered when selecting the crane. These conditions are also relevant when assessing a single girder vs double girder EOT crane for an industrial application.

6. Maintenance and Accessibility

Both single girder EOT and double girder EOT cranes require maintenance. This involves inspecting and servicing parts like the hoist, brake, wheels, motor, electrical circuitry and structural connections.

The simpler design of the single girder crane makes it an option where a simple lifting system is needed. A double girder crane is more complex in terms of structural components.

The workplace itself is also of significance in this regard, as dust, moisture, heat, chemicals and frequent usage may cause the need for increased maintenance of the crane. A set schedule of crane inspections and dealing with components’ wear at the early stages will facilitate reliable crane operation no matter what configuration is chosen.

7. Crane Installation and Building Considerations

The structural design and weight of the crane itself may influence its installation process and the needs of the building it will be installed in. Single girder cranes have a lighter structure, which may come in handy if loads on the building and space considerations are significant issues.

Double girder cranes have a bigger bridge structure and may need extra care concerning the runway and support structure itself. Therefore, the installation of a crane needs consideration of the building layout, runway arrangement, available space and access to the crane itself.

Which Type of Crane Should Be Selected?

This depends upon the actual requirements of the particular application. The selection of the single girder EOT crane would be justified in case there is a need for a relatively compact and economical system for light to medium duty lifting.

A double girder EOT crane would be more appropriate where there is a requirement for relatively heavy loads, higher duty cycles, larger lifting heights or where a stronger bridge structure would be required. A complete single girder vs double girder EOT crane evaluation can help in considering these requirements together.

Conclusion

The selection between a single girder and double girder EOT crane is determined by a number of parameters such as lifting capacity, span, headroom, duty cycle, installation, maintenance and cost. Venus Engineers supplies EOT cranes suitable for handling material in industrial applications. It is essential to know the operating environment and analyze the whole application before choosing a crane.

FAQs

What is the major difference between a single girder and a double girder EOT crane?

The difference lies in the number of girders used in the system: a single girder EOT crane has one girder, while a double girder EOT crane has two parallel girders.
